IB-3 ShingleStarter™ is a 50 mil, self-adhering shingle-starter roofing underlayment. It serves the dual function of replacing conventional starter strips, as well as providing ice and water dam protection in cold climates. IB-3 ShingleStarter has a mineral surface for excellent foot traction.
IB-3 ShingleStarter™ has two self-sealing tabs, each 1.5" nominally from each edge for good adhesion. These sealing strips are protected by a removable release liner, which keeps dust and other debris from settling on the sealing tabs. Keep these liners in place until the shingles are installed. IB-3 ShingleStarter™ installs under roofing at the edges and valleys to protect from leaks due to ice dams, melting snow and blowing rain. IB-3 ShingleStarter™ is suitable for use in new construction and reroofing.
IB-3 ShingleStarter Features
50 mil nominal thickness
Self-sealing tabs on each edge for good adhesion
Installs in temperatures above 40°F
Minimum slope for installation is 2" per foot
Applies easily at eaves, valleys, vents, skylights and chimneys
Easy to remove split release liner for fast installation and ideal for valley applications
Self-seals around common fasteners
May be left exposed for up to 30 days
5-Year limited warranty
IB-3 SHINGLESTARTER Approvals
ASTM D 1970
ICC-ES ESR 1737
LA County (LARC/LABC)
State of California (CRC/CBC)
Florida Building Code FL 11842.1
Miami-Dade County Approved
Texas Department of Insurance Listed
Fortified Building Program Listed
IB-3 ShingleStarter™
| Product | Product ID | Size | Units/Carton | Carton Wt. |
|---|---|---|---|---|
| IB-3 ShingleStarter | 47366 | 36” x 65’ | 1 | 66 lbs |
